L Connector Stud to Al Conductor

Name: L Connector Stud to Al Conductor
Brand: A-1 Electricals
Availability: InStock

L connector for stud to aluminium conductor connection in substation busbar applications.

Material: Al Alloy

Finish: Natural or Electro Tinned

ISO 9001:2015

Quality System

CE / RoHS

Compliant

IEC Tested

Certified

Technical Specifications

Material: Al Alloy

Finish: Natural or Electro Tinned

Specifications

ΦA Min. (mm)	ΦA Max. (mm)	ΦB (mm)	C (mm)	D (mm)
12	15	25	85	85
16	19	25	85	85
20	23	25	85	85
24	26	25	85	85
12	15	30	85	85
16	19	30	85	85
20	23	30	85	85
24	26	30	85	85
27	30	30	85	85
31	32	30	85	85
33	35	30	85	85
36	39	30	85	85
40	43	30	85	85
12	15	40	85	85
16	19	40	85	85
20	23	40	85	85
24	26	40	85	85
27	30	40	85	85
31	32	40	85	85
33	35	40	85	85
36	39	40	85	85
40	43	40	85	85
24	26	50	100	85
27	30	50	100	85
31	32	50	100	85
33	35	50	100	85
36	39	50	100	85
40	43	50	100	85
24	26	60	100	85
27	30	60	100	85
31	32	60	100	85
33	35	60	100	85
36	39	60	100	85
40	43	60	100	85

Notes

D = 85 mm for all combinations. C = 85 mm for ΦB 25u201340 mm; C = 100 mm for ΦB 50 mm and 60 mm.
